Winch system Alpha 4.3 tons for Ford Ranger year 2016-2022

Our horntools winch system for the Ford Ranger complements its front perfectly as it is located behind the front cover. The Alpha 9.5 winch is one of the most popular winches among our customers. The system is ideal for use in rough terrain. To ensure that everything works smoothly during a rescue operation or when pulling equipment, the winch is equipped with a 10 mm thick and 30 m long synthetic rope with a soft thimble.

The winch system is suitable for all T7 models from 2016 to 2022. However, for vehicles with a technology package and distance meter, the sensor must be moved. This must be done by a specialist after prior consultation. The sensor must be recalibrated after installation and the license plate must not be placed exactly in front of the sensor.

Characteristics:

• Motor IP67 sealed by groove with sealing ring
• Freewheel lever
• Stainless steel crossbars
• Reinforced rope drum
• Internal drum brake with 3 brake shoes
• Powder-coated aluminum die-cast housing motor/gearbox
• Removable control unit (so that the control can be installed anywhere)
• Reinforced, powder-coated contractor housing (control box) made of deep-drawn sheet metal


Scope of delivery:

• Installation set
• Winch
• Aluminum cable window
• Fastening screws
• Synthetic rope with soft thimble
• Cable remote control
• Radio remote control
• TÜV parts certificate
• Operation manual

Note for owners with technology package - distance sensor:

For vehicles with a radar sensor and distance sensor installed as standard, the calibration must be clarified with a Ford workshop before ordering or installation.

Danger:

The delivery does not include a holder for the radar sensor.

Please note that our winches may only be used for ground traction and are not suitable for lifting!

The operating instructions for the winch must be read completely before use and must be strictly followed, otherwise there is a risk of injury!

A notice:

You can get all the important information about handling your new winch in the operating instructions and from your specialist dealer. This winch can produce a higher level of noise.
